价 格
订货量
￥8600.00
30 - 59
￥8500.00
价格为商家提供的参考价，请通过"获取最低报价"
获得您最满意的心理价位~
≥60
| 产品特性：光纤网卡 | 品牌：Mellanox NVIDIA | 型号：NVIDIA MCX516A-CCHT ConnectX-5 100GbE双口光纤网卡 |
| 上市时间：2015 | 货源类别：现货 | 配件类型：HCA卡 |
| 产品尺寸：16*12 | 产品重量：0.18KG | 最快出货时间：1-3天 |
| 发票：NO | 售后服务：店面三包 | 包装清单：NO |
NVIDIA MCX516A-CCHT ConnectX-5 100GbE双口光纤网卡
Mellanox MCX516A-CCAT ConnectX-5 EN Network Interface Card 100GbE Dual-Port QSFP28 PCIe3.0 x16 Tall Bracket ROHS R6双口万兆光纤网卡Mellanox迈络思IB光纤交换机Mellanox迈络思以太网交换机Mellanox迈络思光纤适配卡HCA卡Mellanox迈络思交换机电源Infiniband交换机等整机及配件批发
Technology:
Ethernet
Max Speed:
100GbE
Ports:
Dual
Connector Type:
QSFP28/QSFP+/QSFP
PCI:
PCIe3.0 x16
Condition:
New
ECCN:
***991
MCX55***-ECAT ConnectX-5 100GB QSFP28 Mellanox HCA卡Mellanox MCX55***-ECAT ConnectX-5 VPI Adapter Card EDR IB and 100GbE Single-Port QSFP28 PCIe3.0 x16 Tall Bracket ROHS R6
General Information
Manufacturer: Mellanox Technologies Ltd
Manufacturer Part Number: MCX55***-ECAT
Manufacturer Website Address:
Brand Name: Mellanox
Product Line: ConnectX-5
Product Name: ConnectX-5 VPI Adapter Card
Product Type: 100Gigabit Ethernet Card
Interfaces/Ports
Host Interface: PCI Express 3.0 x16
I/O Expansions
Expansion Slot Type: QSFP28
Media & Performance
Media Type Supported: Optical Fiber
Network & Communication
Network Technology: 100GBase-X
Physical Characteristics
Form Factor: Plug-in Card
Width: 2.7"
Depth: 5.6"
Miscellaneous
Device Supported: Server
Environmentally Friendly: Yes
Environmental Certification: RoHS-6
Technology:
InfiniBand
Max Speed:
EDR & 100GbE
Ports:
Single
Connector Type:
QSFP28/QSFP+/QSFP
PCI:
PCIe3.0 x16
Condition:
New
ECCN:
***991
MCX456M-ECAT MCX55***-ECAT Infiniband Mellanox HCA卡批发
| MCX456M-ECAT | with Multi-Host supporting dual-socket server, EDR IB (100Gb/s) and 100GbE, dual-port , QSFP28, dual PCIe3.0 x8 |
| MCX55***-ECAT | EDR IB (100Gb/s) and 100GbE, single-port QSFP28, PCIe3.0 x16 |
MCX45***-FCAT MCX456A-FCAT Infiniband Mellanox HCA卡批发
| MCX45***-FCAT | FDR IB (56Gb/s) and 40/56GbE, single-port QSFP28, PCIe3.0 x16 |
| MCX456A-FCAT | FDR IB (56Gb/s) and 40/56GbE, dual-port QSFP28, PCIe3.0 x16 |
MCX456A-ECAT 100GbE QSFP28双口 Mellanox HCA卡批发
| MCX456A-ECAT | EDR IB (100Gb/s) and 100GbE, dual-port QSFP28, PCIe3.0 x16 |
MCX45***-ECAT 100GbE QSFP28单口 Mellanox HCA卡批发
| MCX45***-ECAT | EDR IB (100Gb/s) and 100GbE, single-port QSFP28, PCIe3.0 x16 |
MCX454A-FCAT 56GbE QSFP28双口IB卡 Mellanox HCA卡批发
| MCX454A-FCAT | FDR IB (56Gb/s) and 40/56GbE, dual-port QSFP28, PCIe3.0 x8 |
MCX453A-FCAT 40/56GbE QSFP28 PCIe3.0 x8 单口 Mellanox HCA卡IB卡Infiniband交换机光纤适配卡批发
MCX453A-FCAT MCX454A-FCAT MCX45***-ECAT MCX45***-FCAT MCX456A-ECAT MCX456A-FCAT MCX456M-ECAT MCX55***-ECAT MCX556A-ECAT MCX556A-EDAT 100GB QSFP28 ConnectX-4 ConnectX-5 Mellanox HCA卡IB卡Infiniband交换机光纤适配卡DAC AOC IB高速电缆 铜缆 光缆Infiniband交换机整机及配件批发
MCX453A-FCAT MCX454A-FCAT MCX45***-ECAT MCX45***-FCAT MCX456A-ECAT MCX456A-FCAT MCX456M-ECAT MCX55***-ECAT MCX556A-ECAT MCX556A-EDAT 100GB QSFP28 ConnectX-4 ConnectX-5 Mellanox HCA卡IB卡Infiniband交换机光纤适配卡DAC AOC IB高速电缆 铜缆 光缆Infiniband交换机整机及配件批发
Item | Description |
| ConnectX-6 VPI 200Gb/s Adapter Card | Supporting up to HDR/200GbE with Virtual Protocol Interconnect and Advanced Offloading Technology |
Part No. | Description |
| MCX55***-ECAT | EDR IB (100Gb/s) and 100GbE, single-port QSFP28, PCIe3.0 x16 |
| MCX556A-ECAT | EDR IB (100Gb/s) and 100GbE, dual-port QSFP28, PCIe3.0 x16 |
| MCX556A-EDAT | EDR IB (100Gb/s) and 100GbE, dual-port QSFP28, PCIe4.0 x16 |
Part No. | Description |
| MCX45***-ECAT | EDR IB (100Gb/s) and 100GbE, single-port QSFP28, PCIe3.0 x16 |
| MCX456A-ECAT | EDR IB (100Gb/s) and 100GbE, dual-port QSFP28, PCIe3.0 x16 |
| MCX45***-FCAT | FDR IB (56Gb/s) and 40/56GbE, single-port QSFP28, PCIe3.0 x16 |
| MCX456A-FCAT | FDR IB (56Gb/s) and 40/56GbE, dual-port QSFP28, PCIe3.0 x16 |
| MCX453A-FCAT | FDR IB (56Gb/s) and 40/56GbE, single-port QSFP28, PCIe3.0 x8 |
| MCX454A-FCAT | FDR IB (56Gb/s) and 40/56GbE, dual-port QSFP28, PCIe3.0 x8 |
| MCX456M-ECAT | with Multi-Host supporting dual-socket server, EDR IB (100Gb/s) and 100GbE, dual-port , QSFP28, dual PCIe3.0 x8 |
Part No. | Description | Dimensions |
| MCX353A-FCCT | Single VPI FDR/40/56GbE | 14.2cm x 5.3cm |
| MCX354A-FCCT | Dual VPI FDR/40/56GbE | 14.2cm x 6.9cm |
Part No. | Description | Dimensions |
| MCX353A-QCBT | Single QDR 40Gb/s or 10GbE | 14.2cm x 5.2cm |
| MCX354A-QCBT | Dual QDR 40Gb/s or 10GbE | 14.2cm x 6.9cm |
| MCX353A-FCBT | Single FDR 56Gb/s or 40/56GbE | 14.2cm x 5.2cm |
| MCX354A-FCBT | Dual FDR 56Gb/s or 40/56GbE | 14.2cm x 6.9cm |
Part No. | Description | PCI Express |
| MCB191A-FCAT | Single FDR 56Gb/s | 3.0 x8 |
| MCB192A-FCAT | Dual FDR 56Gb/s | 3.0 x8 |
| MCB193A-FCAT | Single FDR 56Gb/s | 3.0 x16 |
| MCB194A-FCAT | Dual FDR 56Gb/s | 3.0 x16 |
