| 产品特性：处理单元 | 品牌：NVIDIA Mellanox英伟达.迈络思 | 型号：MCX623436MS-CDAB |
| 上市时间：2019 | 货源类别：现货 | 配件类型：数据处理单元 |
| 产品尺寸：46x16 | 产品重量：0.18KG | 最快出货时间：30天以上 |
| 发票：YES | 售后服务：全国联保 | 包装清单：YES |
MCX623436MS-CDAB MCX623436AN-CDAB MCX623436AC-CDAB MCX623435MN-CDAB MCX623436MN-CDAB MCX623436MS-CDAB MCX623436AS-CDAI MCX62343***C-CDAI MCX62343***C-CDAB MCX62343***E-CDAB IB网卡批发
MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
MCX623430MS-CDAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
MCX631432AN-ADAB ConnectX-6 Lx EN adapter card, 25GbE OCP3.0, w/ Host mgmt , Dual-port SFP28, PCIe 4.0 x8, No Crypto光纤网卡MCX623430MS-CDAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
NVIDIA ConnectX-6 Lx Ethernet SmartNIC
Providing up to two ports of 25GbE connectivity, and PCIe Gen 3.0/4.0 x8 host connectivity, ConnectX-6 Lx MCX631102AS-ADAT is a member of NVIDIA&＃39;s world-class, award-winning, ConnectX family of network adapters. Continuing NVIDIA&＃39;s consistent innovation in networking, ConnectX-6 Lx provides agility and efficiency at every scale. ConnectX-6 Lx delivers cutting edge 25GbE performance and security for uncompromising data centers.
SmartNIC Portfolio
10/25 Gb/s Ethernet
Various form factors:
PCIe low-profile
OCP 3.0 Small Form Factor (SFF)
Connectivity options:
SFP28
PCIe Gen 3.0/4.0 x8
Crypto and non-crypto versions
Features & Applications
Line speed message rate of 75Mpps
Advanced RoCE
ASAP2
Accelerated Switching and Packet Processing
IPsec in-line crypto acceleration
Overlay tunneling accelerations
Stateful rule checking for connection tracking
Hardware Root-of-Trust and secure firmware update
Best-in-class PTP performance
ODCC compatible
MCX631432AC-ADAB ellanox ConnectX-6 Lx EN adapter card, 25GbE, Dual-port SFP28,PCIe 4.0 x8迈络思光纤网卡MCX631432AN-ADAB ConnectX-6 Lx EN adapter card, 25GbE OCP3.0, w/ Host mgmt , Dual-port SFP28, PCIe 4.0 x8, No Crypto光纤网卡MCX623430MS-CDAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
NVIDIA MBF2H332A-AENOT BlueField-2 SmartNIC P-Series DPU 25GbE Dual-Port SFP56 PCIe Gen4 x8 Crypto Disabled 16GB On-Board DDR 1GbE OOB Management Tall Bracket HHHL（非加密）DPU数据处理单元MCX631432AN-ADAB ellanox ConnectX-6 Lx EN adapter card, 25GbE, Dual-port SFP28,PCIe 4.0 x8迈络思光纤网卡MCX631432AN-ADAB ConnectX-6 Lx EN adapter card, 25GbE OCP3.0, w/ Host mgmt , Dual-port SFP28, PCIe 4.0 x8, No Crypto光纤网卡MCX623430MS-CDAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX623432AS-ADAB ConnectX-6 25GB QSFP28双口IB 光纤网卡MCX65310***-ECAT MCX516A-CCAT MCX621102AN-ADAT MCX623102AN-ADAT MCX556A-EDAT 光纤网卡
NVIDIA MBF2H332A-AENOT BlueField-2 SmartNIC （MBF2H332A-AENOT） 技术参数
NVIDIA MBF2H332A-AENOT BlueField-2 SmartNIC P-Series DPU 25GbE Dual-Port SFP56 PCIe Gen4 x8 Crypto Disabled 16GB On-Board DDR 1GbE OOB Management Tall Bracket HHHL（非加密）
Technology :Ethernet
Max Speed :25GbE
Connector Type : QSFP56
Ports : Dual
25GbE双端口SFP56 PCIe Gen4 x8加密禁用16GB板载DDR 1GbE OOB管理高支架HHL
芯片上的数据中心基础设施
英伟达BLUVELD-2数据处理单元（DPU）是一个数据中心基础设施，它为传统的企业、高性能计算（HPC）和现代云工作负载优化，提供了一组广泛的加速软件定义的网络、存储、安全和管理服务。BlueField-2 DPU使企业能够将其IT基础设施转变为进的数据中心，这些数据中心经过加速、完全可编程，并配备零信任安全性，以防止数据泄露和网络攻击。
安全
硬件信任根
正则表达式（RegEx）匹配处理器加速
硬化隔离层
IPsec/TLS和XTS加密
有状态防火墙加速的连接跟踪
存储
GPUDirect存储
通过NVMe快照存储虚拟化实现的弹性块存储
加速器的NVMe
VirtIO-blk加速器
网络
RoCE，零接触RoCE
GPU指令
病毒网络加速器
加速交换和数据包处理（ASAP2）
OVS和OVN加速
| OPN | Marketing Description |
|---|---|
| MCX65110***-EDAT | ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IB and 100GbE, single-port QSFP56, PCIe4.0 x8, tall bracket |
| MCX65310***-HDAT | ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, single-port QSFP56, PCIe4.0 x16, tall bracket |
| ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, dual-port QSFP56, PCIe3.0/4.0 x16, tall bracket | |
| ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IB and 100GbE), single-port QSFP56, PCIe3.0/4.0 x16, tall bracket | |
| ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IB and 100GbE), dual-port QSFP56, PCIe3.0/4.0 x16, tall bracket | |
| MCX68310***N-HDAT | ConnectX-6 DE InfiniBand adapter card, HDR, single-port QSFP, PCIe 3.0/4.0 x16, No Crypto, Tall Bracket |
| MCX65310***-HDAL | ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, single-port QSFP56, PCIe4.0 x16, cold plate for liquid-cooled Intel? Server System D50TNP platforms, tall bracket, ROHS R6 |
| ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, dual-port QSFP56, PCIe4.0 x16, cold plate for liquid-cooled Intel? Server System D50TNP platforms, tall bracket, ROHS R6 | |
| MCX65410***-HCAT | ConnectX-6 VPI adapter card kit, HDR IB (200Gb/s) and 200GbE, single-port QSFP56, Socket Direct 2x PCIe3.0 x16, tall brackets |
ConnectX-6 VPI adapter card, HDR IB (200Gb/s) and 200GbE, dual-port QSFP56, Socket Direct 2x PCIe3.0/4.0x16, tall bracket | |
| ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR InfiniBand and 100GbE), dual-port QSFP56, Socket Direct 2x PCIe3.0/4.0 x16, tall bracket | |
| MCX65310***-EFAT | ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IB and 100GbE), single-port QSFP56, PCIe3.0/4.0 Socket Direct 2x8 in a row, tall bracket |
| ConnectX-6 VPI adapter card, 100Gb/s (HDR100, EDR IBand100GbE), dual-port QSFP56, PCIe3.0/4.0 Socket Direct 2x8 in a row, tall bracket |
Part Number | MCX65110***-EDAT |
|---|---|
Form Factor/Dimensions | PCIe Half Height, Half Length / 167.65mm x 68.90mm |
Data Transmission Rate | Ethernet: 10/25/40/50/100 Gb/s |
Network Connector Type | Single-port QSFP56 |
PCIe x8 through Edge Connector | PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s |
RoHS | RoHS Compliant |
Adapter IC Part Number | MT28908A0-XCCF-HVM |
Part Number | MCX65310***-ECAT | MCX653106A-ECAT | MCX65310***-HDAT | MCX653106A-HDAT |
|---|---|---|---|---|
Form Factor/Dimensions | PCIe Half Height, Half Length / 167.65mm x 68.90mm | |||
Data Transmission Rate | Ethernet: 10/25/40/50/100 Gb/s | Ethernet: 10/25/40/50/100/200 Gb/s | ||
Network Connector Type | Single-port QSFP56 | Dual-port QSFP56 | Single-port QSFP56 | Dual-port QSFP56 |
PCIe x16 through Edge Connector | PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s | |||
RoHS | RoHS Compliant | |||
Adapter IC Part Number | MT28908A0-XCCF-HVM |
Part Number | MCX65310***-HDAL | MCX653106A-HDAL |
|---|---|---|
Form Factor/Dimensions | PCIe Half Height, Half Length / 167.65mm x 68.90mm | |
Data Transmission Rate | Ethernet: 10/25/40/50/100/200 Gb/s | |
Network Connector Type | Single-port QSFP56 | Dual-port QSFP56 |
PCIe x16 through Edge Connector | PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s | |
RoHS | RoHS Compliant | |
Adapter IC Part Number | MT28908A0-XCCF-HVM |
Part Number | MCX65410***-HCAT | MCX654106A-HCAT | MCX654106A-ECAT |
|---|---|---|---|
Form Factor/Dimensions | Adapter Card: PCIe Half Height, Half Length / 167.65mm x 68.90mm | ||
Data Transmission Rate | Ethernet: 10/25/40/50/100/200 Gb/s | Ethernet: 10/25/40/50/100 Gb/s | |
Network Connector Type | Single-port QSFP56 | Dual-port QSFP56 | |
PCIe x16 through Edge Connector | PCIe Gen 3.0 / 4.0SERDES@ 8.0GT/s / 16.0GT/s | ||
PCIe x16 through Auxiliary Card | PCIe Gen 3.0SERDES@ 8.0GT/s | ||
RoHS | RoHS Compliant | ||
Adapter IC Part Number | MT28908A0-XCCF-HVM |
Part Number | MCX65310***-EFAT | MCX653106A-EFAT |
|---|---|---|
Form Factor/Dimensions | PCIe Half Height, Half Length / 167.65mm x 68.90mm | |
Data Transmission Rate | Ethernet: 10/25/40/50/100 Gb/s | |
Network Connector Type | Single-port QSFP56 | Dual-port QSFP56 |
PCIe x16 through Edge Connector | PCIe Gen 3.0 / 4.0 SERDES @ 8.0GT/s / 16.0GT/s Socket Direct 2x8 in a row | |
RoHS | RoHS Compliant | |
Adapter IC Part Number | MT28908A0-XCCF-HVM |
